Body weight measurement

Measuring system

Resistance strain gauge

Body weight index

Automatic intelligent calculation of body mass index

Range of measurement

500kg

Height measurement

Verified precision

±0.1kg

Measuring system

Ultrosonic probe

Range of measurement

70.0~200cm

Verified precision

0.1cm

Blood pressure measurement

Model

Panasonic EW3153 Arm cuff

Display

LCD Digital Display

Measurement Method

Oscillometric method

Measurement Range

Pressure: 0 mmHg to 299 mmHg, Pulse: 40 to 180/min.

Accuracy

Pressure: ±3 mmHg, Pulse: ± 5%

Inflation

Electric pump

Deflation

Automatic pressure release valve

Pressure Detection

Capacitive pressure sensor

Memory

84 Measurements with date and time for each user

(A and B)

Power Source

AC/DC adapter (Included; Input 100-240V 50Hz/60Hz,

AC/DC adapter (Included; Input 100-240V

Output 6V/9.6W)

50Hz/60Hz,Output 6V/9.6W)

10°C to 40°C/30 to 85% RH

Storage temperature/Humidity/Air Pressure

-20°C to 60°C/10 to 95% RH700 - 1060 hPa

Console Weight

Approximately 2600 g

Outer Dimensions

Approximately 286 (l) mm * 294 (w) mm * 271 (h) mm

Arm Circumference

22 to 42 cm

Measurement of fat

Measuring system

Multi-frequency 4- Electrode

Measurement frequency

5kHz/50kHz/250kHz/500kHz

Measurement category

Body fat, Muscle, Visceral fat, Body water, Basal metabolism, Body Type

Material

Electroplating material

Current for measurement

90μA or below

Range of measurement

75.0~1,500.00Ω(0.1ΩUnit)

Body parts of surveyor

Body, right leg, left leg, right arm, left arm

Measurement of blood oxygen

Blood oxygen probe

CREATIVE KS-CM01

Sensor

Dual wavelength LED

Wavelength

"Visible light( Max):663nm

Invisible Light:890nm"

Measurement range

35%~100%

Average output power(Max)

≤2mW

Measurement error

In the range of 70% to 100% < ±2%

Accuracy

In the range of 70% to 100% < ±3%

Pulse rate measurement error

30~250bpm

Monitoring error is ±2bpm or ±%2, whichever is the

largest

Working humidity

5℃~40℃

Relative humidity

15%~95%(Non-condensing)

Atmospheric pressure

70kpa~106kpa

Power supply mode

Powered by ancillary equipment

Range of measurement

95-99%(±2%normal status,±3% motion or weak perfusion,less than 95% undefined)

Body temperature

Infrared thermometer

Calibeur DT-8836

Accuracy

0.1 ℃

Operating Temperature

10~40℃

Storage temperature

0~50℃

Relative humidity

≤85%

Power supply

DC 9V(6F22:a layer-built battery)

Specification

150*75*40mm

Weight

Gross weight:400g, Net weight:172g

Body temperature range

32.0~42.5℃

Object temperature range

0~100℃

Accuracy

≤±0.3℃

Power dissipation

≤120mw

Measurement distance

5-8cm

Auto power off

About 15 seconds
